Design and Analysis of Epicyclic Gear Box

Design and Analysis of Epicyclic Gear Box

Patel, Jignesh J.

Paperback

Technology & Engineering

Currently unavailable to order

ISBN10: 3659686565
ISBN13: 9783659686566
Publisher: Lap Lambert Academic Pub
Published: Jun 15 2018
Pages: 92
Weight: 0.32
Height: 0.22 Width: 6.00 Depth: 9.00
Language: English
The aim of book is to introduce Epicyclic gear box in the domestic motor vehicle replacing the conventional type of synchromesh gear box. For the reference, gear box of Maruti-800 is selected. Wilson Pre selective gear box is selected for the design. By using the same gear ratio of Maruti-800 epicyclic gear box is designed. Design is modified and reworked to meet the standardization of the handbooks been used. FEA has now emerged as an alternative to the traditional analysis techniques. It is widely used now days for analyzing behavior of mechanical components under loading conditions in modern engineering practice. Finite element analysis is a complete idealization of the entire problem including the preparation of solid modeling, Discretization of the structure into finite elements, defining physical and material properties, loads and boundary conditions. The modeling of this manual design is performed using the modeling software Solid works. The modeling is then followed by the static analysis using an analysis software Pro-mechanica. Each results obtained are verified then after by comparing than with existing gear box.
