Conceptual Design Study of a Closed Brayton Cycle Turbogenerator for Space Power Thermal-To-Electric Conversion System

Conceptual Design Study of a Closed Brayton Cycle Turbogenerator for Space Power Thermal-To-Electric Conversion System

Nasa, National Aeronautics and Space Adm

Paperback

Astronomy & Space

Currently unavailable to order

ISBN10: 1723715328
ISBN13: 9781723715327
Publisher: Independently Published
Published: Sep 14 2018
Pages: 40
Weight: 0.26
Height: 0.08 Width: 8.50 Depth: 11.02
Language: English
A conceptual design study was completed for a 360 kW Helium-Xenon closed Brayton cycle turbogenerator. The selected configuration is comprised of a single-shaft gas turbine engine coupled directly to a high-speed generator. The engine turbomachinery includes a 2.5:1 pressure ratio compression system with an inlet corrected flow of 0.44 kg/sec. The single centrifugal stage impeller discharges into a scroll via a vaned diffuser. The scroll routes the air into the cold side sector of the recuperator. The hot gas exits a nuclear reactor radiator at 1300 K and enters the turbine via a single-vaned scroll. The hot gases are expanded through the turbine and then diffused before entering the hot side sector of the recuperator. The single shaft design is supported by air bearings. The high efficiency shaft mounted permanent magnet generator produces an output of 370 kW at a speed of 60,000 rpm. The total weight of the turbogenerator is estimated to be only 123 kg (less than 5% of the total power plant) and has a volume of approximately 0.11 cubic meters. This turbogenerator is a key element in achieving the 40 to 45% overall power plant thermal efficiency.Hansen, Jeff L.Marshall Space Flight CenterTURBINES; TURBOGENERATORS; DESIGN ANALYSIS; SYSTEMS ENGINEERING; GAS TURBINE ENGINES; THERMODYNAMIC EFFICIENCY; CLOSED CYCLES; FREE CONVECTION...
